●  Simple and fashion design , with independent patent

●  The lamp body is made of aluminum alloy die casting, the surface is sprayed by outdoor special plastic powder after passivating treatment

●  Special optical and thermal issue structure design,make sure the light works efficiently and reliable

●  The light source can be selected with high-power 5050LED, medium power 3030LED

●  Transparent super white tempered glass lampshade

●  Light source cavity configuration breathing apparatus, make the cavity pressure balance in vivo and in vitro, eliminate cavity in the fog and condensation, ensure the service life of the output and the LED lamps and lanterns of luminous flux





Order typepower(w)have a lot of social connections L(m)elevation of light h(m)GAP d(m)elevation rAverage illumination (Lx)Minimum illumination (Lx)Maximum illumination (Lx)Minimum photoDegree / averageilluminanceMinimum photoDegree / maximumilluminance
D181-50-215022103613°2813540.4810.25
D181-50-324028123813°2617500.6330.329
Order typepower(w)have a lot of social connections L(m)elevation of light h(m)GAP d(m)elevationAverage illumination (Lx))Minimum illumination (LxMaximum illumination of the area (Lxx)Minimum photoDegree / averageilluminateMinimum photoDegree / maximumilluminate度
D181-30-215022103613°2611610.4270.186
D181-30-320028123813°2514560.5550.245
The product modelS-D181-50-2S-D181-30-2S-D181-50-3S-D181-30-3
Type of the LEDhigh-power 5050In the power 3030high-power 5050In the power 3030
Rated Power200W150W240W200W
Input VoltageAC220V±20%AC220V±20%AC220V±20%AC220V±20%
Frequency Range50/60Hz50/60Hz50/60Hz50/60Hz
Power Factor>0.9>0.9>0.9>0.9
CT of the Light Source(k)3750~42503750~42503750~42503750~4250
Color Rendering Index≥ Ra70≥ Ra70≥ Ra70≥ Ra70
Luminous Efficiency(lm/w)≥ 140≥ 130≥ 140≥ 130
Initial Luminous Flux(lm)28000195003360026000
Lifetime>30000h>30000h>30000h>30000h
Operating Temperature-20℃~+50℃-20℃~+50℃-20℃~+50℃-20℃~+50℃
Operating Humidity10％~90％10％~90％10％~90％10％~90％
Protection GradeIP65IP65IP65IP65
Electric Shock Protection GradeI classI classI classI class
Diameter of the Suitable TubeΦ60mmΦ60mmΦ60mmΦ60mm
Installation Height10~12m10~12m10~12m10~12m
Weight(kg)15.515.515.515.5
Size of the Package(mm)1015*424*2321015*424*2321015*424*2321015*424*232
