•The design inspiration is "sunflower" simple and fasion
•Humanized design , convenient disassembly and assembly, safe and reliable
•High pressure die-casting aluminum , impact resistance and long life
•The lampshade is light diffuser plate lampshade,non-glare
•Light source:medium power LED


The product modelS-J163
Type of the LEDIn the power Medium power
LED Chip Quantity36pcs
Rated Power30W
Input VoltageAC220V±20%
Frequency Range50/60Hz
Power Factor>0.9
CT of the Light Source(k)3750~4250
Color Rendering IndexN Ra70
Initial Luminous Flux(lm)2416
Lifetime>30000h
Operating Temperature-20°C〜+50°C
Operating Humidity10%~90%
Protection GradeIP65
Electric Shock Protection GradeI类
Installation Height3~5m
Weight(kg)3.5
Size of the Package(mm)534x534x210
 Order typeHeight (mm)Foundation No.Pole section size (mm)Pole material
J163-G1193400B-010 75/114 steel
J163-G1103500B-010 75/114 steel
J163-G1333900B-01089/140 steel
J163-G9004500B-01089/130 steel
