●  Streamline form design, simple and fashion, with independent patent
●  Humanized design, convenient disassembly and assembly, safe and reliable
●  High pressure die-casting aluminum, impact resistance and long life
●  The lampshade is optical PC, high-temperature resistance and anti-aging
●  The main light source is multiple chip integration package LED
●  Auxiliary light source: single chip LED




mounting heightcoefficient of correction
5 m1.440
6 m1.000
7 m0.735
8 m0.563
9 m0.444
10 m0.360
11 m0.298
12 m0.250
13 m0.213
14 m0.184
15 m0.160
16 m0.141

The product modelS-J121AS-J121B
Main Type of the LEDCOB--------
Main LED Chip Quantity1pc--------
Auxiliary Type of the LED high-power high-power
Auxiliary LED Chip Quantity18pcs18pcs
Rated Power85W45W
Input VoltageAC220V±20％AC220V±20％
Frequency Range50/60Hz50/60Hz
Power Factor>0.9>0.9
CT of the Light Source(k)3750~42503750~4250
Color Rendering Index≥ Ra70≥ Ra70
Luminous Efficiency(lm/w)≥ 90--------
Initial Luminous Flux(lm)76503600
Lifetime>30000h>30000h
Operating Temperature-20℃~+50℃-20℃~+50℃
Operating Humidity10％~90％10％~90％
Protection GradeIP65IP65
Diameter of the suitable tubeΦ114mmΦ114mm
Installation Height4~8m4~8m
Weight(kg)149.95
Size of the Package(mm)1110×430×3001110×430×300
