J171-Jinan Sanxing Lighting Technology Co.,LTD

J171

MESSAGR

● Simple and fashion design, with independent patent

● Combined with steel and aluminum, the surface is sprayed by outdoorspecial plastic powder

● Special optical and thermal issue structure design,make sure the light works efficiently and reliable

● The light source is using high luminous efficiency LED

Order type				Function Module
	Lighting module	WIFI module	Public broadcasting module	Decorative lamp module	Projection lamp module	Charging pile module	Monitoring moduleMonitoring module

parameter	Power of the main lamp: 19W / 50WPower of auxiliary lamp: 10WColor temperature of main light source: 3000K	Wireless frequency band: 2.4GHz, 5GHzMaximum rate: 1,900 M b p sAntenna type: omnidirectional 360Cover radius: 100 mMaximum standby and standby: 60 people	Power: 30WCommunication protocol: TCP / IP, SIP, UDP, ARP, ICMP, IGMPFrequency response: 50Hz-20KHzAudio Sampling: 8kHz~44.1kHz,16bitAudio encode: MP2 / MP3 / PCM / ADPCM	Power:, 14WLight source wavelength:450~465nm	Power: 30WProjection picture customizationProjection picture ratio: 1:0.3	Rated power: 7KWCharging mode: AC single chargeinput voltage:AC220V±15%Payment method: swipe card, QR code codeLevel of protection: IP54Working environment temperature: -20℃ ~ + 50℃	Pixels: 200WVideo compression: H.265/,H.264/MJPEGNumber change in times: 16 timesOptical doubling: 4 x
尺寸 (mm)	Φ230×610	Φ230×500	Φ230×660	Φ230×140	Φ230×605	Φ230×593	Φ230×436
J171-1	●			●
J171-2	●				●
J171-3	●	●	●	●
J171-4	●		●	●
J171-5	●			●	●
J171-6	●		●	●	●
J171-8	●	●		●			●
J171-11	●	●		●
J171-12	●		●	●	●		●
J171-13	●	●	●	●			●
J171-16	●	●	●	●	●	●	●


