D211

‹

›

‹

  • D211
  • D211
  • D211
  • D211

›

Power:80～150W/150～200W
Luminous(lm/w):135～115/ 130～120
Material: Aluminum alloy die-casting
Installation height: 6～8m/10～12m
MESSAGR
CONTACT US

●  Simple and fashion design, with independent patent

●  Aluminum alloy die-casting, the surface is sprayed by outdoor special plastic powder

●  Humanized design, convenient disassembly and assembly, safe and reliable

●  The ultra - white tempered glass is not easy to be contaminated with dust and oil

●  The reflector is special optical design, with high reflection efficiency and low glare

●  The light source is using high luminous efficiency LED








mounting heightcoefficient of correction
5 m4.000
6 m2.778
7 m2.041
8 m1.563
9 m1.235
10 m1.000
11 m0.826
12 m0.694
13 m0.592
14 m0.510
15 m0.444
16 m0.391
Type of the LEDIn the power 3030In the power 3030
LED Chip Quantity160pcs240pcs
Power80~150W150~200W
Input VoltageAC220V±20％AC220V±20％
Frequency Range50/60Hz50/60Hz
Power Factor>0.9>0.9
CT of the Light Source(k)3750~42503750~4250
Luminous Efficiency(lm/w)135~115130~120
Color Rendering Index≥ Ra70≥ Ra70
Lifetime>30000h>30000h
Operating Temperature-20℃~+50℃-20℃~+50℃
Operating Humidity10％~90％10％~90％
Protection GradeIP65IP65
Electric Shock Protection GradeI classI class
Diameter of the Suitable TubeΦ60mmΦ60mm
Installation Height6~8m10~12m
Weight(kg)5.16.2
Size of the Package(mm)247×860×205（2 The outfit）247×1010×205（2 The outfit）
