J161-Jinan Sanxing Lighting Technology Co.,LTD

J161

Power:35W/38W
Material: High pressure die-casting aluminum
Installation height: 4～5m

MESSAGR

• Simple and fashion design, with independent patent

• Humanized design, convenient disassembly and assembly, safe and reliable

• High pressure die-casting aluminum, impact resistance and long life

• Light source: medium power LED

The product model	J161A	J161B	J161C
Main Type of the LED	In the power	In the power	In the power
Auxiliary Type of the LED	high-power	In the power	In the power
Rated Power	35W	38W	38W
Input Voltage	AC220V±20%	AC220V±20%	AC220V±20%
Frequency Range	50/60Hz	50/60Hz	50/60Hz
Power Factor	>0.9	>0.9	>0.9
CT of the Main Light Source(k)	3750~4250	3750~4250	3750~4250
CT of the Auxiliary Light Source(k)	585-595nm(波长)	3000	3000
Color Rendering Index	N Ra70	N Ra70	N Ra70
Lifetime	>30000h	>30000h	>30000h
Operating Temperature	-20°C〜+50°C	-20°C〜+50°C	-20°C〜+50°C
Operating Humidity	10%~90%	10%~90%	10%~90%
Protection Grade	IP65	IP65	IP65
Electric Shock Protection Grade	Iclass	Iclass	Iclass
Diameter of the suitable tube	①60mm	①60mm

Installation Height	4~5m	3~5m	4~5m
Weight(kg)	8.6	6.9	5.9
Size of the Package(mm)	608x608x236	608x608x414	608x608x317(2The outfit)


